R/C Mercedes-Benz Actros 3363 6×4 GigaSpace

Tamiya 56348

This is Tamiya 1/14 Tractor Trucks Mercedes Benz Actros 3363 6×4 GigaSpace EP.

This is a highly accurate 1/14 scale radio control model that recreates the Mercedes Benz Actros 3363 3-axle truck. The Actros series debuted in 2011 and was named 2012 Truck of the Year. Powered by a 15.6-liter inline-6 turbocharged diesel putting out a max of 630hp, the actual 3363 can haul up to 250 tons!

The Tamiya rendition faithfully captures the truck’s modern form with the use of ABS plastic body parts and a number of metal chassis components. One look at the detailed interior and auxiliary equipment, such as air tanks, will confirm that the body features replica-quality realism, which is further enhanced with metal transfers depicting emblems and numerous metal-plated parts. The chassis is built for durability as it uses aluminum side channels with resin cross members. Drivability is accomplished by power from the front-mounted motor and is transmitted via a propeller shaft to the rear axle; built-in differential gears guarantee smooth cornering. Gear changes can be made via a separately-sold 4-channel transmitter.

The Actros’ realism can be further heightened with separately-available trailers that can be attached to its coupler and make the model over a meter in length!

Feature:

• Scale: 1/14
• Construction Type: Assembly kit
• Terrain Use: On-Road
• Drive-train: 4-axle semi
• Drive Type: Gearbox
• Drive Line: Dog bone
• Differential type: Gear
• Suspension: Leaf spring
• Steering mechanism: Bell-crank
• Shock damper: friction damper
• Shock Damper Material: Aluminum
• Tire Type: Rubber
• Tire tread: Radial
• Body material: ABS Plastic
• Chassis material: Aluminum & plastic
• ESC: Not Included
• ESC model: N/A
• LED Light buckets: Yes
• LED lights: No
• Motor: 540-brushed type
• Bearings: Metal bushings
• Adjustable camber: Fixed
• Adjustable toe angles: Front only
• Adjustable ground clearance: Fixed
• Adjustable gear ratio: 3-speed transmission
• Adjustable wheelbase: Fixed
• Adjustable track width: Fixed
• Adjustable shock angle: Fixed
• Special feature 1: The body of the Actros 3363 is recreated accurately using newly-molded parts differentiating it from the 1851 spec model.
• Special feature 2: The tried and tested Tamiya 3-axle chassis utilizes a tough ladder frame with aluminium side channels and resin cross members. A realistic drivetrain setup sees the front mounted motor powering twin rear axles.
• Special feature 3: 3-speed transmission can be controlled via a 4ch R/C transmitter. Item 7255252 is the perfect radio to complement the Actros kit.
• Special feature 4: Metal leaf spring dampers with built-in coil springs provide durable suspension.
• Special feature 5: Coupler is included to enable connection with any currently available Tamiya 1/14 scale trailers.
• Special feature 6: Compatible with the tractor truck option parts (TROP) Items 56531, 56532 and 56536. Use with Multi-Function Control Unit MFC-03 (Item 56523) (or MFC-01, Item 56511) for realistic LED lights and sounds.

Specification:

• Length: 538mm
• Width: 195mm
• Height: 305mm

Require:

• 4-channel radio gear
• 7.2 battery & charger
• ESC
• Servo
• TS plastic model paint
