Tritronic 1X 60A Waterproof Brushed ESC

Yeah Racing ESC-1X

Description:

Aluminum heatsink brushed ESC with a minimal footprint designed for crawlers! Easy adjust settings switching between drive modes and battery voltage cutoff with simple jumper plugs located at the front of the ESC.

Feature:

• For: 1/10: Touring Car ( Buggy, Short Course Truck, Monster, Truggy, Rock Crawler and Tank )

• Water-proof and dust-proof, suitable for all-weather condition races.

• Small size with built-in capacitor module.

• Fwd/Rev/Br running mode fits for various vehicles (Fwd =Forward, Br=Brake, Rev=Reverse).

• Great current endurance capability.

• Great built-in BEC output capacity.

• Automatic throttle range calibration, easy to use.

• Easy to set the ESC parameters with jumpers.

• Multiple protections: Low voltage cut-off protection for battery / Over-heat protection / Throttle signal loss protection.

• Aluminium Heat Sink

Specification:

• Fwd. Cont. / Peak Current: 60A /360A

• Rev. Cont. / Peak Current: 30A /180A

• Voltage Range: 2-3S Lipo or 5-9 NiMH

• 2S Lipo or 6 NiMH

  -1/10 Touring Buggy Crawler Short Course Truck : 540/ 550 Motor 12T Or RPM<30000

• 3S Lipo or 9 NiMH

  -1/10 Buggy Crawler Short Course Truck : 540/550 Motor 35TOr RPM< 20000 (Suggest additional capacitor when use 3S lipo battery)

• Resistance: Fwd 0.001[, Rev 0.002[

• BEC Output: 3A/6V (Linear Mode)

• PWM Frequency: 1KHz

• Dimension : 36.5*32*18mm


• Weight: : 39g


• Cooling Fan: Without cooling fan

Include:

• Tritronic 1X ESC (1 pc)

• Manual
